| Grid overview |
|---|
| Apple | Touch Pass |
|---|
| Display | Nej |
|---|
| Livestream | Nej |
|---|
| NFC | Nej |
|---|
| Physical Unlock | Nej |
|---|
| Sound | Two-Way Audio |
|---|
| Weatherproof | Outdoor Covered |
|---|
| Lock Terminals | Nej |
|---|
| AI | AI Detections |
|---|
| IR | 5 m (16 ft) |
|---|
| Connection | Nej |
|---|
| Lens Resolution | 8 MP Camera |
|---|
| Overview |
|---|
| Dimensions | 176 x 45 x 29.6 mm
(6.9 x 1.8 x 1.2") |
|---|
| Integrated Camera | Ja |
|---|
| IR Night Vision | 5 m (16 ft) |
|---|
| Resolution | Main camera: 5MP
Package camera: 8MP |
|---|
| UniFi Application Suite | Protect
Access |
|---|
| Face Recognition | Ja |
|---|
| NFC Card & Keyfob Access | Ja |
|---|
| PIN Access | Nej |
|---|
| QR Code Unlock | Nej |
|---|
| Touch Pass | Nej |
|---|
| Apple/Google Wallet | Ja |
|---|
| Mobile Unlock | Ja |
|---|
| Face Unlock | Ja |
|---|
| Handwave Request to Exit | Nej |
|---|
| Fingerprint Unlock | Nej |
|---|
| Fingerprint Capacity | Nej |
|---|
| Two-Way Intercom & Doorbell Access | Ja |
|---|
| Weatherproofing | IP55 |
|---|
| Smart Detections (People, Vehicles, Animals) | Ja |
|---|
| Tamper Resistance | IK07 |
|---|
| Audio | Two-way audio |
|---|
| Maximum User Count | Nej |
|---|
| Tamper Switch | Nej |
|---|
| UL 294 Level | Destructive attack: Level I
Line security: Level I
Endurance: Level I
Standby power: Level I |
|---|
| NDAA Compliant | Ja |
|---|
| Mechanical |
|---|
| Weight | 275 g (9.7 oz) |
|---|
| Enclosure Material | Aluminum |
|---|
| Mount Material | Wall mount: Stainless steel
Gangbox mount plate: SGCC steel
Gangbox mount cover: Polycarbonate
Wedge mount: Aluminum |
|---|
| Mounting | Wall mount, Gangbox mount plate, 20° wedge mount (Included)
Junction box (Optional) |
|---|
| Hardware |
|---|
| Indoor and Outdoor Use | Yes |
|---|
| Networking Interface | GbE RJ45 port |
|---|
| Connectivity | BLE 4.1
NFC |
|---|
| Security | Nej |
|---|
| Power Method | PoE+
UL 294 Power-limited Class 2 PSU
UL 60950-1/62368-1 LPS/PS2 PSU |
|---|
| Max. Power Consumption | 16W |
|---|
| Supported Voltage Range | 42—57V DC |
|---|
| ESD/EMP Protection | Nej |
|---|
| Powered Output Relay | Nej |
|---|
| Video: Image Settings | Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay, HDR |
|---|
| Video: Max. Frame Rate | Main camera: 30 FPS
Package camera: 3 FPS |
|---|
| Video: Resolution | Main camera: 5MP, 1920 x 2560 (3:4)
Package camera: 8MP 3264 x 2448 (4:3) |
|---|
| Optics: Resolution | Main camera: 5MP CMOS
Package camera: 8MP CMOS |
|---|
| Optics: Field of View | Main camera: H: 100°, V: 135°, D: 180°
Package camera: H: 66°, V: 51.7°, D: 78° |
|---|
| Optics: Sensor | Main camera: 5MP CMOS
Package camera: 8MP CMOS |
|---|
| Optics: Lens | Fixed focal length |
|---|
| Optics: Night Mode | Built-in IR LED illumination and IR cut filter |
|---|
| Sensors | Nej |
|---|
| Display: Size | Nej |
|---|
| Display: Screen Technology | Nej |
|---|
| Display: Luminance | Nej |
|---|
| Display: Screen Orientation | Nej |
|---|
| Display: Resolution | Nej |
|---|
| Microphone | Nej |
|---|
| Speaker | Nej |
|---|
| LEDs | R/G/B/W
<a href="https://help.ui.com/hc/en-us/articles/25738084762775-Understanding-UniFi-Access-Device-LED-Status-Indicators" target="_blank" rel="noopener noreferrer">Learn More</a> |
|---|
| Button | (1) Ring button
(1) Factory reset
(1) Tamper switch |
|---|
| Processor | Quad-core Arm® Cortex®-A53 based chip |
|---|
| NFC Frequency | Nej |
|---|
| NFC Read Range | Nej |
|---|
| NFC Technology | Nej |
|---|
| PoE Cabling Requirements | Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site.
The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm² ) for patch cords; 24 AWG (0.21 mm² ) for horizontal or riser cable. |
|---|
| UL 294 Statement | Compliance with IEEE 802.3 specifications was not verified as part of UL 294.
The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits. |
|---|
| CAN/ULC-60839-11-1 Grade | Grade assignment: I |
|---|
| Certifications | CE, FCC, IC, UL 294, CAN/ULC-60839-11-1 |
|---|
| Document number, and issue date and/or revision level | UVC-G6-Entry, V01 |
|---|
| Ambient Operating Temperature | -30 to 50° C (-22 to 122° F) |
|---|
| Ambient Operating Humidity | 5 to 90% noncondensing |
|---|
