| Grid overview |
|---|
| IDS/IPS | 2.3 Gbps |
|---|
| App Suite | Nej |
|---|
| Max. Client Count | 300 |
|---|
| Ports | Nej |
|---|
| Security | Nej |
|---|
| Storage | Nej |
|---|
| RADIUS over TLS (RadSec) | Ja |
|---|
| IDS/IPS Throughput | 2.3 Gbps |
|---|
| Overview |
|---|
| Dimensions | 117 x 117 x 42.5 mm
(4.61 x 4.61 x 1.67'') |
|---|
| UniFi Application Suite: Network | Ja |
|---|
| UniFi Application Suite: Protect | Nej |
|---|
| UniFi Application Suite: Access | Nej |
|---|
| UniFi Application Suite: Talk | Nej |
|---|
| UniFi Application Suite: Connect | Nej |
|---|
| Managed UniFi Devices | 30+ |
|---|
| Managed Cameras | Nej |
|---|
| Managed Access Hubs | Nej |
|---|
| Simultaneous Users Connected | 300+ |
|---|
| Max. WAN Port Count | 1 |
|---|
| Default WAN Ports | (1) 10 GbE RJ45 |
|---|
| Port Layout: 1 GbE RJ45 | Nej |
|---|
| Port Layout: 2.5 GbE RJ45 | 1
(2.5G/1G/100M/10M) |
|---|
| Port Layout: 10 GbE RJ45 | 1
(10G/5G/2.5G/1G/100M) |
|---|
| Port Layout: 10G SFP+ | Nej |
|---|
| Port Layout: 25G SFP28 | Nej |
|---|
| Port Layout: 100G QSFP28 | Nej |
|---|
| Port Layout: MGMT | Nej |
|---|
| Port Layout: Console | Nej |
|---|
| Capacity: SSL/TLS Inspection Concurrent Sessions | Nej |
|---|
| Capacity: Concurrent Sessions | Nej |
|---|
| Capacity: New Sessions / Second | Nej |
|---|
| Form Factor | Compact desktop |
|---|
| Redundancy | Nej |
|---|
| Coverage Area | 160 m² (1,750 ft²) |
|---|
| Mounting | Nej |
|---|
| Weight | Nej |
|---|
| Enclosure Material | Nej |
|---|
| Mount Material | Nej |
|---|
| Compute Capacity | Nej |
|---|
| Security |
|---|
| Stateful Firewall | Ja |
|---|
| Application-Aware Layer 7 Firewall | Ja |
|---|
| SSL Inspection & URL Filtering | Nej |
|---|
| DPI & Traffic Identification | Ja |
|---|
| Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps) | Ja |
|---|
| Content Filtering | Ja |
|---|
| Intrusion Prevention (IPS/IDS) | Ja |
|---|
| Ad Blocking | Ja |
|---|
| IDS/IPS Signatures | 20,000+ with CyberSecure |
|---|
| VLAN/Subnet-based Traffic Segmentation | Ja |
|---|
| VPN & SD-WAN |
|---|
| License-Free SD-WAN | Ja |
|---|
| Site-to-Site VPN: Site Magic | Ja |
|---|
| Site-to-Site VPN: IPsec | Ja |
|---|
| Site-to-Site VPN: OpenVPN | Ja |
|---|
| VPN Server: Identity Endpoint One-Click VPN | Ja |
|---|
| VPN Server: Teleport Zero-Configuration VPN | Ja |
|---|
| VPN Server: WireGuard | Ja |
|---|
| VPN Server: OpenVPN | Ja |
|---|
| VPN Server: L2TP | Ja |
|---|
| VPN Client: OpenVPN | Ja |
|---|
| VPN Client: WireGuard | Ja |
|---|
| VPN Server Single User Throughput: Identity Endpoint One-Click VPN | Nej |
|---|
| VPN Server Single User Throughput: Teleport | Nej |
|---|
| VPN Server Single User Throughput: WireGuard | Nej |
|---|
| VPN Server Single User Throughput: OpenVPN | Nej |
|---|
| VPN Server Single User Throughput: L2TP | Nej |
|---|
| Site-to-Site VPN Single Tunnel Throughput: Site Magic | Nej |
|---|
| Site-to-Site VPN Single Tunnel Throughput: OpenVPN | Nej |
|---|
| Site-to-Site VPN Single Tunnel Throughput: IPsec | Nej |
|---|
| VPN Client Single Tunnel Throughput: WireGuard | Nej |
|---|
| VPN Client Single Tunnel Throughput: OpenVPN | Nej |
|---|
| Networking |
|---|
| Multi-WAN Load Balancing | Nej |
|---|
| Shadow Mode (VRRP) High Availability | Nej |
|---|
| LACP Port Aggregation | Nej |
|---|
| Dynamic Routing: OSPF | Ja |
|---|
| Dynamic Routing: BGP | Nej |
|---|
| Advanced QoS | Ja |
|---|
| Multicast DNS (mDNS) | Ja |
|---|
| Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT) | Ja |
|---|
| Integrated RADIUS Server | Ja |
|---|
| Additional Internet Failover with UniFi LTE Backup | Ja |
|---|
| Internet Quality and Outage Reporting | Ja |
|---|
| MAC Address Table Size | Nej |
|---|
| Policy-based WAN and VPN Routing | Ja |
|---|
| Customizable DHCP Server | Ja |
|---|
| IPv6 ISP Support | Ja |
|---|
| IGMP Proxy | Ja |
|---|
| Virtual Network Override | Ja |
|---|
| All Traffic Flows | Nej |
|---|
| Integrated WiFi |
|---|
| WiFi Standard | 802.11a/b/g/n/ac/ax/be (WiFi 6/6E, WiFi 7) |
|---|
| Throughput: 6 GHz | 5.7 Gbps |
|---|
| Throughput: 5 GHz | 4.3 Gbps |
|---|
| Throughput: 2.4 GHz | 688 Mbps |
|---|
| MIMO: 6 GHz | 2 x 2 (DL/UL MU-MIMO) |
|---|
| MIMO: 5 GHz | 2 x 2 (DL/UL MU-MIMO) |
|---|
| MIMO: 2.4 GHz | 2 x 2 (DL/UL MU-MIMO) |
|---|
| Antenna Gain: 6 GHz | 6 dBi |
|---|
| Antenna Gain: 5 GHz | 7 dBi |
|---|
| Antenna Gain: 2.4 GHz | 4 dBi |
|---|
| Max. TX Power: 6 GHz | 24 dBm |
|---|
| Max. TX Power: 5 GHz | 26 dBm |
|---|
| Max. TX Power: 2.4 GHz | 23 dBm |
|---|
| Wireless Security | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK) |
|---|
| Max. BSSIDs | 4 per Radio (Gateway Mode)
4 per Radio (AP Mode) |
|---|
| Antennas | Nej |
|---|
| Supported Data Rates: 802.11be (WiFi 7) | 7.3 Mbps to 5.7 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320) |
|---|
| Supported Data Rates: 802.11ax (WiFi 6/6E) | 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160) |
|---|
| Supported Data Rates: 802.11ax (WiFi 6) | Nej |
|---|
| Supported Data Rates: 802.11ac (WiFi 5) | 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) |
|---|
| Supported Data Rates: 802.11n | 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) |
|---|
| Supported Data Rates: 802.11g | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
|---|
| Supported Data Rates: 802.11b | 1, 2, 5.5, 11 Mbps |
|---|
| Supported Data Rates: 802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
|---|
| Hardware |
|---|
| NVR Storage | Nej |
|---|
| Expansion Slot | Nej |
|---|
| Networking Interface | Nej |
|---|
| PoE Budget | Nej |
|---|
| Max. PoE Wattage per Port by PSE: PoE | Nej |
|---|
| Max. PoE Wattage per Port by PSE: PoE+ | Nej |
|---|
| Max. PoE Wattage per Port by PSE: PoE++ | Nej |
|---|
| Max. PoE Wattage per Port by PSE: PoE+++ | Nej |
|---|
| Voltage Range PoE Mode | Nej |
|---|
| Max. Power Consumption | 22W |
|---|
| Power Method | USB type C (5V DC/5A) |
|---|
| Power Supply | USB type C (5V DC/5A)
(Adapter included) |
|---|
| Supported Voltage Range | 100–240V AC |
|---|
| Heat Dissipation | 75 BTU/hr |
|---|
| Processor | Quad-core ARM® Cortex®-A53 at 1.5 GHz |
|---|
| Memory | Nej |
|---|
| System Memory | 3 GB |
|---|
| On-board Storage | Nej |
|---|
| LCM Display | 0.96" status display |
|---|
| Management | Ethernet
Bluetooth |
|---|
| LEDs: Ethernet | Ja |
|---|
| LEDs: SFP+ | Nej |
|---|
| LEDs: SFP28 | Nej |
|---|
| LEDs: QSFP28 | Nej |
|---|
| LEDs: System | Nej |
|---|
| LEDs: RPS | Nej |
|---|
| LEDs: PSU | Nej |
|---|
| LEDs: HDD | Nej |
|---|
| LEDs: Swappable Fan | Nej |
|---|
| LEDs: AC Outlet | Nej |
|---|
| LEDs: CRPS | Nej |
|---|
| LEDs: MicroSD | Nej |
|---|
| LEDs: SIM | Nej |
|---|
| Button | (1) Factory reset |
|---|
| ESD/EMP Protection | Air: ± 8kV, contact: ± 4kV |
|---|
| Ambient Operating Temperature | -10 to 40° C (14 to 104° F) |
|---|
| Ambient Operating Humidity | 5 to 95% noncondensing |
|---|
| NDAA Compliant | Ja |
|---|
| Certifications | CE, FCC, IC, Anatel: 06656-25-08356 |
|---|
| Software |
|---|
| VLAN | 802.1Q |
|---|
| Guest Traffic Isolation | Ja |
|---|
| Application Requirements: UniFi Network | Version 9.0.108 and later |
|---|
| Application Requirements: Web Application | Nej |
|---|
| Application Requirements: Mobile App | Nej |
|---|
