| Mechanical |
|---|
| Dimensions | 249.3 x 82 x 47.6 mm
(9.8 x 3.2 x 1.9") |
|---|
| Weight | 575 g (1.3 lb) |
|---|
| Enclosure Material | Aluminum alloy, UV-resistant polycarbonate |
|---|
| Mount Material | Strap: stainless steel
Universal bracket: UV-resistant polycarbonate |
|---|
| Mounting | Pole Mount |
|---|
| Pole Mount Diameter | 1—2" (25.4—50.8 mm) |
|---|
| Wind Loading | Nej |
|---|
| Weatherproofing | IPX6 |
|---|
| Hardware |
|---|
| Processor | Quad-core IPQ5322 at 1.5 GHz |
|---|
| Memory | DDR4 1 GB |
|---|
| Networking Interface | (1) 10 GbE RJ45 port
(1) 10G SFP+ port |
|---|
| Management Interface | Nej |
|---|
| Max. Power Consumption | 20W |
|---|
| Power Method | Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-)
Passive PoE 2-pairs (4, 5+; 7, 8-), for 44–54V DC only |
|---|
| Supported Voltage Range | 44–54V DC
22–27V DC |
|---|
| Power Supply | 54V DC, 0.56A, 10 GbE PoE adapter (Included) |
|---|
| MIMO: 5 GHz | (2) 2 x 2 |
|---|
| MIMO: 6 GHz | Nej |
|---|
| Max. TX Power: 5 GHz | 24 dBm |
|---|
| Max. TX Power: 6 GHz | Nej |
|---|
| GPS | Ja |
|---|
| RF Connections | (2) RP-SMA (Waterproof)
(1) GPS (Waterproof) |
|---|
| ESD Protection | Nej |
|---|
| Buttons | (1) Factory reset |
|---|
| LEDs: Power | (1) Blue |
|---|
| LEDs: Ethernet | (1) Blue |
|---|
| LEDs: GPS | (1) Blue |
|---|
| LEDs: Link | Nej |
|---|
| LEDs: 60G | Nej |
|---|
| LEDs: SFP+ | Nej |
|---|
| LEDs: Light Ring | Nej |
|---|
| LEDs: Signal Strength | (4) Blue |
|---|
| Ambient Operating Temperature | -40 to 60° C (-40 to 140° F) |
|---|
| Ambient Operating Humidity | 5 to 95% noncondensing |
|---|
| NDAA Compliant | Ja |
|---|
| Certifications | FCC, IC, CE |
|---|
| Software |
|---|
| Operating Modes | PtP |
|---|
| Ubiquiti Specific Features: airMAX AC Mode | Nej |
|---|
| Ubiquiti Specific Features: Ackless Mode | Nej |
|---|
| Ubiquiti Specific Features: Discovery Protocol | Nej |
|---|
| Ubiquiti Specific Features: Frequency Band Offset | Nej |
|---|
| Ubiquiti Specific Features: 30/50/60 MHz Channels | Nej |
|---|
| Ubiquiti Specific Features: Traffic Shaping with Burst Support | Nej |
|---|
| Services: UISP | Ja |
|---|
| Services: Ping Watchdog | Ja |
|---|
| Services: NTP Client | Ja |
|---|
| Services: System Log | Nej |
|---|
| Services: SNMP | Nej |
|---|
| Tools: Cable Test | Nej |
|---|
| Tools: Wave AI | Nej |
|---|
| Tools: Wave Technology | Nej |
|---|
| Utilities: airMagic | Nej |
|---|
| Utilities: airView® | Nej |
|---|
| Utilities: Antenna Alignment | Ja |
|---|
| Utilities: Ping | Ja |
|---|
| Utilities: Site Survey | Ja |
|---|
| Utilities: Speed Test | Ja |
|---|
| Utilities: Traceroute | Ja |
|---|
| Utilities: Discovery Utility | Ja |
|---|
| Network | Bridge Mode |
|---|
| Application Requirements: UISP | Nej |
|---|
| Application Requirements: UISP web | Nej |
|---|
| Application Requirements: UISP mobile iOS™ | Nej |
|---|
| Application Requirements: UISP mobile Android™ | Nej |
|---|
| System |
|---|
| Total Throughput | 5+ Gbps |
|---|
| Supported Clients | Nej |
|---|
| Max. Range | 100 km (62.1 mi) |
|---|
| Encryption | WPA3-PSK (AES) |
|---|
| Radio Frequency |
|---|
| Operating Frequency: US/CA | Nej |
|---|
| Operating Frequency: Worldwide | 5180 – 5320 MHz
5500 – 5700 MHz
5745 – 5825 MHz |
|---|
| Channel Bandwidth | Radio 1: 20, 40, 80, 160 MHz
Radio 2: 20, 40, 80, 160, 240 MHz |
|---|
| Operating Channels | Nej |
|---|
| Modulation | BPSK (½), QPSK (½), QPSK (¾), 16QAM (½), 16QAM (¾), 64QAM (⅔), 64QAM (¾), 64QAM (⅚), 256QAM (¾), 256QAM (⅚), 1024QAM (¾), 1024QAM (⅚), 4096QAM (¾), 4096QAM (⅚) |
|---|
| Antenna Gain | Nej |
|---|
| Polarization | Nej |
|---|
| Beamwidth | Nej |
|---|
| Cross-Pol Isolation | Nej |
|---|
| Electrical Downtilt | Nej |
|---|
