| Mechanical |
|---|
| Dimensions | ⌀256.5 x 113.5 mm
(⌀10.1 x 4.5") |
|---|
| Weight | Without mount: 932 g (2.1 lb)
With mount: 1.2 kg (2.6 lb) |
|---|
| Enclosure Material | Aluminum alloy, UV stabilized polycarbonate |
|---|
| Mount Material | Aluminum alloy, UV stabilized polycarbonate |
|---|
| Mounting | Pole Mount |
|---|
| Pole Mount Diameter | 25 to 63.5 mm (1 to 2.5") |
|---|
| Wind Loading | 127 N at 200 km/h (28.6 lbf at 125 mph) |
|---|
| Weatherproofing | IPX6 |
|---|
| Hardware |
|---|
| Processor | Dual-core ARM® Cortex®-A53 at 1 GHz |
|---|
| Memory | 512 MB |
|---|
| Networking Interface | (1) GbE RJ45 port |
|---|
| Management Interface | Nej |
|---|
| Max. Power Consumption | 20W |
|---|
| Power Method | Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-)
Passive PoE 2-pairs (4, 5+; 7, 8-), for 44–54V DC only |
|---|
| Supported Voltage Range | 44–54V DC
22–27V DC |
|---|
| Power Supply | 48V DC, 0.65A gigabit PoE adapter (Included) |
|---|
| MIMO: 5 GHz | Nej |
|---|
| MIMO: 6 GHz | Nej |
|---|
| Max. TX Power: 5 GHz | Nej |
|---|
| Max. TX Power: 6 GHz | Nej |
|---|
| GPS | Ja |
|---|
| RF Connections | Nej |
|---|
| ESD Protection | Nej |
|---|
| Buttons | (1) Factory reset |
|---|
| LEDs: Power | Flashing white: bootup in progress
White: not connected to UISP application
Blue: connected to UISP application
Flashing blue: locate in progress
Blue/white: firmware upgrade in progress |
|---|
| LEDs: Ethernet | Flashing blue: Ethernet traffic detected |
|---|
| LEDs: GPS | Blue: receiving at least (4) GPS satellite signal |
|---|
| LEDs: Link | White: 5 GHz link
Blue: 60 GHz link |
|---|
| LEDs: 60G | Nej |
|---|
| LEDs: SFP+ | Nej |
|---|
| LEDs: Light Ring | Nej |
|---|
| LEDs: Signal Strength | Nej |
|---|
| Ambient Operating Temperature | -40 to 60° C (-40 to 140° F) |
|---|
| Ambient Operating Humidity | 5 to 95% noncondensing |
|---|
| NDAA Compliant | Ja |
|---|
| Certifications | FCC, IC, CE |
|---|
| Software |
|---|
| Operating Modes | PtP
PtMP Station |
|---|
| Ubiquiti Specific Features: airMAX AC Mode | Nej |
|---|
| Ubiquiti Specific Features: Ackless Mode | Nej |
|---|
| Ubiquiti Specific Features: Discovery Protocol | Ja |
|---|
| Ubiquiti Specific Features: Frequency Band Offset | Nej |
|---|
| Ubiquiti Specific Features: 30/50/60 MHz Channels | Nej |
|---|
| Ubiquiti Specific Features: Traffic Shaping with Burst Support | Ja |
|---|
| Services: UISP | Ja |
|---|
| Services: Ping Watchdog | Ja |
|---|
| Services: NTP Client | Ja |
|---|
| Services: System Log | Nej |
|---|
| Services: SNMP | Ja |
|---|
| Tools: Cable Test | Ja |
|---|
| Tools: Wave AI | Ja |
|---|
| Tools: Wave Technology | Ja |
|---|
| Utilities: airMagic | Nej |
|---|
| Utilities: airView® | Nej |
|---|
| Utilities: Antenna Alignment | Ja |
|---|
| Utilities: Ping | Ja |
|---|
| Utilities: Site Survey | Ja |
|---|
| Utilities: Speed Test | Ja |
|---|
| Utilities: Traceroute | Ja |
|---|
| Utilities: Discovery Utility | Nej |
|---|
| Network | Bridge/Router mode |
|---|
| Application Requirements: UISP | Version 1.4.5 and later |
|---|
| Application Requirements: UISP web | Nej |
|---|
| Application Requirements: UISP mobile iOS™ | Nej |
|---|
| Application Requirements: UISP mobile Android™ | Nej |
|---|
| System |
|---|
| Total Throughput | 2 Gbps |
|---|
| Supported Clients | Nej |
|---|
| Max. Range | 5+ km (3.1 mi) |
|---|
| Encryption | WPA2-PSK (AES) |
|---|
| Radio Frequency |
|---|
| Operating Frequency: US/CA | Nej |
|---|
| Operating Frequency: Worldwide | 57–71 GHz |
|---|
| Channel Bandwidth | 2160, 1080, 540 MHz |
|---|
| Operating Channels | 58320, 59400, 60480, 61560, 62640, 63720, 64800, 65880, 66960, 68040, 69120, 70200, 70560 MHz |
|---|
| Modulation | 16QAM, QPSK |
|---|
| Antenna Gain | 41 dBi |
|---|
| Polarization | Vertically-Linear |
|---|
| Beamwidth | Azimuth: 3 dB 1.4°
Elevation: 3 dB 1.4° |
|---|
| Cross-Pol Isolation | Nej |
|---|
| Electrical Downtilt | Nej |
|---|
| Radio Frequency (Back-Up) |
|---|
| WiFi Standard | 802.11ax (WiFi 6) |
|---|
